Increase your process efficiency and recovery rate X-ray fluorescence spectroscopy (XRF) has an important and well-established analytical role within the mining and minerals industry. It is used extensively for exploration, grade control, process monitoring and assuring that the composition of waste is within the limits of environmental norms and regulations.

Epsilon 4 benchtop spectrometers are used in mining operations, even at remote locations, for fast elemental analysis of ores, minerals and rocks. The combination of low infrastructural demands and the high analytical performance, enables quick determination of operation strategies in mining locations where utilities are limited.

Discover the possibilities of XRF analysis and reduce your feedback time from hours to minutes by placing the benchtop XRF spectrometer next to your mine or processing plant.

Technical Specifications

Types of samplesPowders (loose and pressed), fused beads, metals, liquids, films, large samples
X-ray tube settingsSoftware controlled: max 50 kV / 2 mA / 10 W
X-ray tube typesMetal-ceramic, side-window
Detector typesHigh-resolution Si drift detector SDD10
Detector resolution< 145 eV @ 5.9 keV cps
Typically 135 eV @ 5.9 keV cps
Power consumption250 VA
Data processingBuilt-in 4096 multi-channel analyser (MCA)
Dimensions (H x W x D)270 x 530 x 510 mm
Weight47 kg

Key Features

Epsilon 4

  • Reduce helium consumption
  • Calibrated for years
  • Online remote support
  • Accurate results
  • Ultimate light-elemental performance
  • Quality results through mature software
  • Safety guaranteed
  • Unattended operation
